C6 MAXIN20X95
MAXIN power chucks with CAMFIX (ISO 26623-1 standard) exchangeable, tapered shanks.
| Body Diameter (BD) | 51 mm | Connection Diameter Minimum Workpiece Side (DCONNWS) | 6 mm |
| Protruding Length (LPR) | 96 mm | Measurement Type | Metric |
| Connection Diameter Maximum Workpiece Side (DCONXWS) | 20 mm | Body Material | Steel |
| Shank Size (SS) | 63 | Unit | M |
| Tool Type | ISO 26623-1 (CAMFIX, CAPTO) |
Product Features
| Family Description | MAXIN power chucks with CAMFIX (ISO 26623-1 standard) exchangeable, tapered shanks. | FamilyName | C#-MAXIN |
| Remarks | Can be used for carbide and HSS tools The adjustment screw has an internal coolant hole Use of DCONXWS diameter tools provides best performance, as collets reduce the gripping force. | BrandName | Iscar |
| COO | Israel |
Shipping Info
Weight per item
1.7630
Name
Milling Chucks
FamilyName
C#-MAXIN
BrandName
Iscar
