HTP D3.00-06-1.00-R-LN16
TANGPLUNGE, Shell mill plungers carrying tangentially clamped inserts with 4 cutting edges. .55″ side plunging capacity and .118″ maximum face milling DOC. Provide excellent side wall surface finish and a flat bottom.
| Application | | Facing | Shouldering | Side Plunging | | Coolant Supply Property (CSP) | Coolant Thru |
| Cutting Diameter (DC) | 3″ | Cutting Direction (HAND) | Right Hand |
| Cutting Item Count (CICT) | 6 | Measurement Type | Inch |
| Depth of Cut Maximum (APMX) | 0.118″ | Tool Type | Plungers cutters |
| Connection Diameter Machine Side (DCONMS) | 1″ | Body Material | Steel |
| Face Effective Cutting Edge Count (ZEFF) | 6 | Body Diameter (BD) | 2.362″ |
| Overall Length (OAL) | 2″ | Unit | I |
Product Features
| Family Description | TANGPLUNGE, Shell mill plungers carrying tangentially clamped inserts with 4 cutting edges. .55″ side plunging capacity and .118″ maximum face milling DOC. Provide excellent side wall surface finish and a flat bottom. | FamilyName | HTP-R-LN16 |
| Remarks | .551 side plunging capacity and .118 maximum face milling DOC For adaptation, click on More Info | BrandName | Iscar |
| COO | Israel |
Shipping Info
Weight per item
2.0128
Name
Plunge Mills
FamilyName
HTP-R-LN16
BrandName
Iscar
